DHK025-33 Ingiant USB 3.0 slip ring hole diameter 25mm with 2 channels USB 3.0 signal and other signals /power

Short Description:

Product Detail

Product Tags

DHK025-33
The main parameters
Number of circuits	33	Working temperature	“-40℃~+65℃”
Rated current	2A.5A.10A.15A.20A	Working humidity	＜70%
Rated voltage	0~240 VAC/VDC	Protection level	IP54
Insulation resistance	≥1000MΩ @500VDC	Housing material	Aluminum Alloy
Insulation strength	1500 VAC@50Hz,60s,2mA	Electrical contact material	Precious metal
Dynamic resistance variation	＜10MΩ	Lead wire specification	Colored Teflon insulated & tinned stranded flexible wire
Rotating speed	0~600rpm	Lead wire length	500mm + 20mm

Standard product outline drawing:

USB slip ring – USB 3.0 slip ring series

Standard 1-3 channels USB signal, maximum 5 channels

DHK025-33 USB 3.0 slip ring with standard hole diameter 25mm, transmission 2 channels USB3.0 signal and other signal/power.USB slip ring is specially designed for USB signal transmission, with the characteristics of multi-channel and stable signal transmission. The USB 2.0 slip ring and USB 3.0 slip ring series are two major series designed to address the issues of large capacity and high efficiency between rotating system components. The rate data transmission provides the best technical solution.

Features

High transmission rate, USB3.0 slip ring theoretical transmission rate 5.0Gbps
Electrical signal transmission scheme & photoelectric conversion transmission scheme optional
Can be mixed with power signals and other complex signals for transmission
Excellent electrical contact materials ensure low noise and ultra-long life of signal transmission
Plug and play USB interface connector, Type A, Type B and micro interface optional
Stable transmission, no packet loss, low insertion loss.

Typical applications:

Closed circuit monitoring spherical gimbal
Electrical testing equipment
Manufacturing and processing control equipment
Exhibition/Display Equipment
robot
Medical equipment
Rotating worktable

Our Advantage

1） Product advantage: Cost effective,High quality,IP protection rated,Suitable for extreme environments, Explosion proof units, High reliability low maintenance, Integration of high frequency channels , Standard units and custom design, Transmission of high definition video with high frame rate, 360 degree continuous panning, Integration of rotary joints and Ethernet, Fully gimbaled systems, Twist capsule integration ,Long life.
2） INGIANT adheres to the business philosophy of “customer-centered, quality-based, innovation-driven”, seeks to win the market with high-quality products and considerate services, in terms of pre-sales, production, after-sales and product warrenty, we provide customized service to meet various demands of clients so Ingiant obtained a excellent reputation from the industry.
3) Customized advantage: Leading Manufacturer of Standard, Customized Slip Ring & Rotary Unions for Many Industries.High Quality Components, Lower Costs, Over 800 Million Revolutions, 20+Years Working Life,Premium Expert Service,Reliable Quality,Competitive Price.
