DHS055-11-2F Ingiant Photoelectric Slip Ring OD 55mm with 2 channels optical fiber and 11 channels power
|
DHS055-11-2F |
|||
|
The main parameters |
|||
|
Number of circuits |
11 |
Working temperature |
“-40℃~+65℃” |
|
Rated current |
can be customized |
Working humidity |
＜70% |
|
Rated voltage |
0~240 VAC/VDC |
Protection level |
IP54 |
|
Insulation resistance |
≥1000MΩ @500VDC |
Housing material |
Aluminum Alloy |
|
Insulation strength |
1500 VAC@50Hz,60s,2mA |
Electrical contact material |
Precious metal |
|
Dynamic resistance variation |
＜10MΩ |
Lead wire specification |
Colored Teflon insulated & tinned stranded flexible wire |
|
Rotating speed |
0~600rpm |
Lead wire length |
500mm + 20mm |
Standard product outline drawing:
Photoelectric Slip Ring/ Photoelectric Rotary Joint
2 channels optical fiber combination electric slip ring, supports customization
DHS055-11-2F Photoelectric slip ring, with 2 channels optical fiber, 11 channels power, outer diameter 55mm, supports single-mode and multi-mode,uses optical fiber as data transmission carrier, suitable for harsh environments, solves the rotation transmission problem for optical series and optoelectronic systems.
Product features
- Large data transmission capacity, high transmission rate
- Suitable for long-distance transmission
- No packet loss, no electromagnetic interference
- Compact design, light weight
- Applicable to harsh environments
- Ultra-long service life
Typical applications:
High-end robots, high-end material conveying systems, rotating turrets, remote control systems, radar antennas, fiber optic sensors and other turntables (rate tables) for high-speed video, digital, and analog signal transmission and control, medical systems, video surveillance systems, submarine operation systems to ensure national or international security systems, emergency lighting equipment, robots, exhibition/display equipment, medical equipment, etc.;
