DHS057-149 Ingiant Customized OD 57mm Ethernet slip ring 149 channels for box type turntable centrifuge
|
DHS057-149 |
|||
|
The main parameters |
|||
|
Number of circuits |
149 |
Working temperature |
“-40℃~+65℃” |
|
Rated current |
can be customized |
Working humidity |
＜70% |
|
Rated voltage |
0~240 VAC/VDC |
Protection level |
IP54 |
|
Insulation resistance |
≥1000MΩ @500VDC |
Housing material |
Aluminum Alloy |
|
Insulation strength |
1500 VAC@50Hz,60s,2mA |
Electrical contact material |
Precious metal |
|
Dynamic resistance variation |
＜10MΩ |
Lead wire specification |
Colored Teflon insulated & tinned stranded flexible wire |
|
Rotating speed |
0~600rpm |
Lead wire length |
500mm + 20mm |
Standard product outline drawing:
DHS057-149 series Ethernet slip ring is an industrial-grade Ethernet slip ring with an outer diameter of 57 mm and flange installation. It is a compact integral structure 1-channel 100M/1000M Ethernet integral precision conductive slip ring that can transmit power current, signals, etc. in a mixed manner! It has the advantages of stable transmission, no packet loss, no string code, small return loss, and small insertion loss. American military coating technology, precious metal + super-hard gold plating, ultra-low BER bit error rate and ultra-high signal-to-noise ratio.
Features
- It has the advantages of stable transmission, no packet loss, anti-crosstalk, large return loss and low insertion loss
- The brush-bundle contact structure ensures product life
- Stable transmission of 1-2 Gigabit Ethernet signals
- Integrated structure design, easy to install
- Protection level IP51-IP68 optional
- Standard models are available and can be customized
- RJ45 male and female connectors are optional
- Use high-quality Ethernet cable
- Maintenance-free
Our advantage:
- Product advantage: Ethernet slip rings are made of reliable precious metal materials and aluminum shells. The mature and stable process makes the produced slip rings have the remarkable characteristics of stable transmission, no packet loss, anti-crosstalk, large return loss and small insertion loss.
- Company advantage: Transmission technology for complex industrial and safety-relevant applications form the core of our product range. All products can be individually adapted to the applications in order to offer you added value. Premium engineering – that is our claim for every single product we manufacture. We would like to convince you of this.
- Customized advantage: We can supply you with quantities from 1. Special shapes or special types are possible on request. Give us a call. We will discuss your challenges until we have found your optimal slip ring. Trust our competence and experience. Our encapsulated miniature slip rings are used in tens of thousands of applications worldwide.
