INGIANT 1000M Ethernet slip ring with hollow shaft hole diameter 25mm 19channels

Short Description:

Ethernet series 1000M Ethernet slip ring

Features：

The Ethernet slip ring is specially designed for 250MHz frequency signals.
It is designed to transmit 100M/1000M Ethernet signals.
It has stable transmission, no packet loss, no cross-coding, small return loss, small insertion loss, strong anti-interference ability, and supports POE Etc.
Ethernet slip rings can mix electrical power paths and signal paths.
It can transmit up to 8 Ethernet channels at the same time, and provides RJ45 connector for direct plugging and unplugging Support RJ45 connector, ultra-low BER bit error rate and ultra-high signal-to-noise ratio.
Various types of Ethernet slip rings, Gigabit network cable slip rings, and 1000M network slip rings can be customized

Product Detail

Product Tags

DHK025-19
The main parameters
Number of circuits	19	Working temperature	“-40℃~+65℃”
Rated current	2A.5A.10A.15A.20A	Working humidity	＜70%
Rated voltage	0~240 VAC/VDC	Protection level	IP54
Insulation resistance	≥1000MΩ @500VDC	Housing material	Aluminum Alloy
Insulation strength	1500 VAC@50Hz,60s,2mA	Electrical contact material	Precious metal
Dynamic resistance variation	＜10MΩ	Lead wire specification	Colored Teflon insulated & tinned stranded flexible wire
Rotating speed	0~600rpm	Lead wire length	500mm + 20mm

Standard product outline drawing:

Ethernet series 1000M Ethernet slip ring

Features：

The Ethernet slip ring is specially designed for 250MHz frequency signals.
It is designed to transmit 100M/1000M Ethernet signals.
It has stable transmission, no packet loss, no cross-coding, small return loss, small insertion loss, strong anti-interference ability, and supports POE Etc.
Ethernet slip rings can mix electrical power paths and signal paths.
It can transmit up to 8 Ethernet channels at the same time, and provides RJ45 connector for direct plugging and unplugging Support RJ45 connector, ultra-low BER bit error rate and ultra-high signal-to-noise ratio.
Various types of Ethernet slip rings, Gigabit network cable slip rings, and 1000M network slip rings can be customized

Typical Applications：

Industrial Machinery – Combined machining center machine tools, rotary indexing tables; Heavy equipment turrets, cable reels, test equipment; Packaging machines, stackers, magnetic clutches, process equipment; Rotary sensors, emergency lighting, robotics; Exhibition/display equipment , medical equipment。
