Ingiant 100M Ethernet slip ring out diameter 28mm with 2 channels 100M Ethernet signal and 1-30 power channels
|
DHS028-49 |
|||
|
The main parameters |
|||
|
Number of circuits |
49 |
Working temperature |
“-40℃~+65℃” |
|
Rated current |
can be customized |
Working humidity |
＜70% |
|
Rated voltage |
0~240 VAC/VDC |
Protection level |
IP54 |
|
Insulation resistance |
≥1000MΩ @500VDC |
Housing material |
Aluminum Alloy |
|
Insulation strength |
1500 VAC@50Hz,60s,2mA |
Electrical contact material |
Precious metal |
|
Dynamic resistance variation |
＜10MΩ |
Lead wire specification |
Colored Teflon insulated & tinned stranded flexible wire |
|
Rotating speed |
0~600rpm |
Lead wire length |
500mm + 20mm |
Standard product outline drawing:
Ethernet slip ring – DHS028 series
Accept customization, transmit 100/1000M Ethernet signal
DHS028-49 100M Ethernet slip ring, outer diameter 28mm, can integrate transmission of 5A current/2A signal/100M Ethernet signal. Plug-and-play type with RJ45 connector, also called network cable slip ring. Ethernet slip rings are made of reliable precious metal materials and aluminum shell. The mature and stable process makes the produced slip rings have the remarkable characteristics of stable transmission, no packet loss, anti-crosstalk, large return loss and small insertion loss.
Product features
- Stable transmission of 2-way 100M Ethernet signals
- The brush contact part is plated with rare precious metals, which has a long service life
- Plug-and-play RJ45 interface
- Dedicated Ethernet cable
- Small size, easy installation
- Stable transmission, no packet loss, no string code, large return loss, low insertion loss
Typical applications
- Small network system
- Video surveillance system
- Stage control system
- Industrial automation control
- Various network cables and RJ45 interface transmission
Our advantage:
- Product advantage: High-quality encapsulated miniature slip rings for combined power and signal transmission for use in space-critical applications. Mechanical and electrical specifications can be adapted according to individual requirements.
- Company advantage: Experienced technical team, perfect manufacturing, quality control and management system, adhering to the value of quality and service first, to provide products and technical services to meet user needs. And constantly increase the investment in the research and development of new slip ring technology, expand the new application field of the slip ring industry. To provide users with more comprehensive product and technical support.
- Customized advantage: Can provide all kinds of industries of non-standard customized slip ring design, can customize different needs of the slip ring, integrated current, signal, gas and liquid as one integrated slip ring. To provide global customers with wind power generation, servo control.
