Ingiant 13mm inner diameter through hole industrial bus slip ring used for radar

Short Description:

Industrial bus slip ring DHK013-25-001 series, inner diameter 13mm, through-hole structure, suitable for rotation applications requiring outer diameter ≤ 13mm. 25-channel hybrid Ethernet, servo power supply, radar power supply and other signal transmission

Features

Can transmit current, sensor, control circuit, Ethernet and other signals

Stable performance, large return loss, small insertion loss, anti-crosstalk

Unique coating process, long service life

Optional RJ45 network interface

Compatible with data communication protocols

Send email to us

Product Detail

Product Tags

DHK013-25-001
The main parameters
Number of circuits	25	Working temperature	“-40℃~+65℃”
Rated current	2A.5A.10A.15A.20A	Working humidity	＜70%
Rated voltage	0~240 VAC/VDC	Protection level	IP54
Insulation resistance	≥1000MΩ @500VDC	Housing material	Aluminum Alloy
Insulation strength	1500 VAC@50Hz,60s,2mA	Electrical contact material	Precious metal
Dynamic resistance variation	＜10MΩ	Lead wire specification	Colored Teflon insulated & tinned stranded flexible wire
Rotating speed	0~600rpm	Lead wire length	500mm + 20mm

Standard product outline drawing:

Industrial bus slip rings are specially designed for various industrial bus data transmission. Supports different bus types, such as CANBUS, Profibus, EtherNET, DeviceNET, RS422, RS485, RS232, PLC, DP, CC-LINK, etc.

Features

Can transmit current, sensor, control circuit, Ethernet and other signals
Stable performance, large return loss, small insertion loss, anti-crosstalk
Unique coating process, long service life
Optional RJ45 network interface
Compatible with data communication protocols

Our Advantage

Product advantage: continuous transmission of power, signals, weak current, high current, high voltage under 360 degree unrestrained rotations. Low torque, low electrical noise, low loss and easy maintenance as the main features.
Company advantage: As manufacturer of various slip ring bodies,Ingiant elies on a combination of targeted design processes, a selection of the best raw materials, professional production conditions, 100% quality control and professional assembly at the customer’s site.
Customised advantage: we offer modular slip ring systems that can be completely individually adapted to your needs. our slip ring bodies are convincing even under rough environmental conditions and temperatures.
