Ingiant 30mm series high precision Ethernet slip ring can be customized

Short Description:

Ethernet slip ring DHS030 series, with an outer diameter of 30mm, can integrate and transmit 5A current/2A signal/1000M Ethernet signal. Plug and play type with RJ45 connector, also called network slip ring, network cable slip ring.



Features

  • Stable transmission of 1-2 channels of 100M Ethernet signals
  • The contact part of the brush is plated with rare precious metals and has a long service life.
  • Plug and play RJ45 interface
  • Dedicated Ethernet cable
  • Small size, easy to install
  • Stable transmission, no packet loss, no cross-coding, large return loss, low insertion loss


Product Detail

Product Tags

DHS030-21

The main parameters

Number of circuits

21

Working temperature

“-40℃~+65℃”

Rated current

can be customized

Working humidity

<70%

Rated voltage

0~240 VAC/VDC

Protection level

IP54

Insulation resistance

≥1000MΩ @500VDC

Housing material

Aluminum Alloy

Insulation strength

1500 VAC@50Hz,60s,2mA

Electrical contact material

Precious metal

Dynamic resistance variation

<10MΩ

Lead wire specification

Colored Teflon insulated & tinned stranded flexible wire

Rotating speed

0~600rpm

Lead wire length

500mm + 20mm

Product drawing:

DHS039-23-004

      Ethernet slip ring DHS030 series, with an outer diameter of 30mm, can integrate and transmit 5A current/2A signal/1000M Ethernet signal. Plug and play type with RJ45 connector, also called network slip ring, network cable slip ring.



Features

  • Stable transmission of 1-2 channels of 100M Ethernet signals
  • The contact part of the brush is plated with rare precious metals and has a long service life.
  • Plug and play RJ45 interface
  • Dedicated Ethernet cable
  • Small size, easy to install
  • Stable transmission, no packet loss, no cross-coding, large return loss, low insertion loss



Typical applications

  • small network system
  • video surveillance system
  • stage control system
  • Industrial automation control
  • Various network cables and RJ45 interface transmission

QQ图片20230322163852

Our advantage:

  • Product advantage: Transmit analog and digital signal;Adopts gold-to-gold contact to transmit signal;Able to integrate up to 135 channels;Module design, guarantees consistency of the products;Compact structure, small size;Adopt special soft wire ;Long life, maintenance-free, easy to install, more stable performance and 360°continuous rotation to transmit power and data siganls.
  • Company advantage:   Ingiant covers an area of more than 8000 square meters of scientific research & production space and with a professional design & manufacturing team of more than 150 staffs; The company owns complete mechanical processing equipment including a CNC processing center, with strict inspection and testing standards which can meet national military GJB standard and quality management system
  • Excellent aftersales advantage: The goods are guaranteed for 12 months from date of sale,under guaranteed time non human damage, free maintenance or replacement for quality problems arising from the products.Provide technical information and technical training support on a regular basis.
