Ingiant 90mm 3-channel RF rotary joint + electrical + 2channels 100M network signal
|
DHS090-21-3S |
|||
|
The main parameters |
|||
|
Number of circuits |
21 |
Working temperature |
“-40℃~+65℃” |
|
Rated current |
can be customized |
Working humidity |
＜70% |
|
Rated voltage |
0~240 VAC/VDC |
Protection level |
IP54 |
|
Insulation resistance |
≥1000MΩ @500VDC |
Housing material |
Aluminum Alloy |
|
Insulation strength |
1500 VAC@50Hz,60s,2mA |
Electrical contact material |
Precious metal |
|
Dynamic resistance variation |
＜10MΩ |
Lead wire specification |
Colored Teflon insulated & tinned stranded flexible wire |
|
Rotating speed |
0~600rpm |
Lead wire length |
500mm + 20mm |
Product drawing:
DHS090 series RF slip ring RF rotary joint
3-channel RF rotary joint + electrical + 100M network signal combination slip ring
Products specially developed to meet the transmission of high-speed serial digital signals or analog signals. The maximum transmission rate can reach 40GHz.
This series of products supports the independent transmission of single-channel high-frequency signals, and can also support the mixed transmission of high-frequency signals and 24V control signals, communication signals, power supplies, and fluid media.
Features：
- Support 1,2,3,4,6,8 high frequency channels
- Can mix 1~96 channels of power/signal
- Perfect standing wave ratio VSWR
- Suitable for large-capacity data transmission without delay
- High-speed transmission of ultra-high-definition video data
- Widely used in satellites, radars, mobile antennas, mobile communications and other equipment
- Various types of high-frequency slip rings, high-frequency rotary joints, high-frequency rotary joints, coaxial rotary joints, waveguide rotary connectors, etc. can be customized.
Applications include radar antennas, military, air traffic control, space and other fields that often require receiving and transmitting multiple frequency signals.
Our advantage:
- Product advantage: Cost effective,High quality,IP protection rated,Suitable for extreme environments, Explosion proof units, High reliability low maintenance, Integration of high frequency channels , Standard units and custom design, Transmission of high definition video with high frame rate, 360 degree continuous panning, Integration of rotary joints and Ethernet, Fully gimbaled systems, Twist capsule integration ,Long life.
- Company advantage: We have more than 50 national patents, and a experienced R&D team with more than 10 years experienced senior engineers in the industry, more than 100 workers with several years experience in workshop production, skilled in operation and production, can better guarantee product quality.
- Excellent after-sales and technical support service:Customized, accurate and timely service for customers in terms of pre-sales, production, after-sales and product warrenty, our goods are guaranteed for 12 months from date of sale,under guaranteed time non human damage, free maintenance or replacement for quality problems arising from the products.
