Ingiant Automation slip rings 82 channels be used for industrial power and signal transmission

Short Description:

Automation Slip Rings

Automation slip rings with outer diameter 56mm to 119mm, transmission of power and data

Automation slip rings for high rotational speed and industrial automation



The automation slip rings are available in housing diameters of 56mm to 119mm in versions with rotor and stator flange or without flange. Inside the housing, 2 to 108 rings can be processed for power and signal transmission (Ethernet, USB, RS, CANbus, video signals, sensor signals, etc.). The housing is made of aluminium. Inside the automation slip rings we use the most advanced fibre brush technology and silver-to-silver or gold-to-gold multi-contacting. The slip rings feature low electrical noise for high data rate field bus transmission, low contact pressure and long life. We offer standardised & modularised design and fully customisable products according to customers’ specific requirements in various applications.


Product Detail

Product Tags

DHS080-82

The main parameters

Number of circuits

82

Working temperature

“-40℃~+65℃”

Rated current

can be customized

Working humidity

<70%

Rated voltage

0~240 VAC/VDC

Protection level

IP54

Insulation resistance

≥1000MΩ @500VDC

Housing material

Aluminum Alloy

Insulation strength

1500 VAC@50Hz,60s,2mA

Electrical contact material

Precious metal

Dynamic resistance variation

<10MΩ

Lead wire specification

Colored Teflon insulated & tinned stranded flexible wire

Rotating speed

0~600rpm

Lead wire length

500mm + 20mm

Product drawing:

DHS012-6-1A

Automation Slip Rings

  • Automation slip rings with outer diameter 56mm to 119mm, transmission of power and data
  • Automation slip rings for high rotational speed and industrial automation



The automation slip rings are available in housing diameters of 56mm to 119mm in versions with rotor and stator flange or without flange. Inside the housing, 2 to 108 rings can be processed for power and signal transmission (Ethernet, USB, RS, CANbus, video signals, sensor signals, etc.). The housing is made of aluminium. Inside the automation slip rings we use the most advanced fibre brush technology and silver-to-silver or gold-to-gold multi-contacting. The slip rings feature low electrical noise for high data rate field bus transmission, low contact pressure and long life. We offer standardised & modularised design and fully customisable products according to customers’ specific requirements in various applications.



 Automation slip rings offer you the following advantages:

  • Shielding against interfering signals
  • Impact-resistant housing
  • acid-resistant housing material
  • Corrosion-resistant enclosure
  • Minimum internal wear and tear
  • Very reliable signal transmission
  • Long-life ball bearings

QQ图片20230322163852

Our advantage:

  1. Product advantage: Compact slip rings for complex industrial power and signal transmission. Advanced fibre brush technology for long life and low contact resistance. Combined power and signal transmission possible.
  2. Company advantage: We have more than 50 national patents, and a experienced R&D team with more than 10 years experienced senior engineers in the industry, more than 100 workers with several years experience in workshop production, skilled in operation and production, can better guarantee product quality.
  3. Customised advantage: Leading Manufacturer of Standard, Customized Slip Ring & Rotary Unions for Many Industries.High Quality Components, Lower Costs, Over 800 Million Revolutions, 20+Years Working Life,Premium Expert Service,Reliable Quality,Competitive Price.

QQ截图20230322163935
