Ingiant Extra large hole 420mm through hole slip ring with 8 channels Ethernet signal

Standard product outline drawing:

Extra large hole through hole slip ring DHK420-106 series

DHK420-106 series hollow shaft through hole slip ring, inner hole 420mm, suitable for rotating electromechanical systems with diameter less than 420mm, standard power ring 20A/ring, maximum 48 rings, signal ring 5A/ring, maximum 96 rings, adopts stainless steel structure , used to transmit power or signals in 360-degree rotating systems. Mostly used in large welding equipment.

Features

• Multi-contact brush contact design, long service life
• Integrated structural design, easy to install
• Power ring 20A/ring, maximum 48 rings, signal ring 5A/ring, maximum 96 rings
• IP 54 protection level, IP68 can be customized
• Can integrate multiple signals and be compatible with multiple data protocols
• Maintenance-free use

Typical applications:

Medical equipment, CNC turntables, CNC machining centers, automation equipment, robotic arms, wire reels, cable reels, packaging machinery, filling equipment, wind turbines, etc.

Our Advantage：

1）Product advantage: The brush filaments used by Ingiant are made of precious metal materials such as silver alloy and gold alloy, and the overall service life of the conductive slip ring is increased through advanced fiber brush bundle contacts. The main features are low torque, low electrical noise, low loss and easy maintenance.

2）Company advantage: We have more than 50 national patents, and a experienced R&D team with more than 10 years experienced senior engineers in the industry, more than 100 workers with several years experience in workshop production, skilled in operation and production, can better guarantee product quality.

3）Customised advantage: Leading Manufacturer of Standard, Customized Slip Ring & Rotary Unions for Many Industries.High Quality Components, Lower Costs, Over 800 Million Revolutions, 20+Years Working Life,Premium Expert Service,Reliable Quality,Competitive Price.
