Ingiant HD-SDI slip rings diameter 95mm 57 channels for perfect broadcasting

Short Description:

Transmission of video signals HD-SDI Slip Rings

Loss-free transmission of high-frequency image and sound signals via HDMI (UHD, 4K, 8K, etc.)


Product Detail

Product Tags

DHS095-57

The main parameters

Number of circuits

57

Working temperature

“-40℃~+65℃”

Rated current

can be customized

Working humidity

<70%

Rated voltage

0~240 VAC/VDC

Protection level

IP54

Insulation resistance

≥1000MΩ @500VDC

Housing material

Aluminum Alloy

Insulation strength

1500 VAC@50Hz,60s,2mA

Electrical contact material

Precious metal

Dynamic resistance variation

<10MΩ

Lead wire specification

Colored Teflon insulated & tinned stranded flexible wire

Rotating speed

0~600rpm

Lead wire length

500mm + 20mm

Product drawing:

DHS075-35

Transmission of video signals HD-SDI Slip Rings

Loss-free transmission of high-frequency image and sound signals via HDMI (UHD, 4K, 8K, etc.)

HD-SDI slip rings for perfect broadcasting

SDI stands for “Serial Digital Interface”. It describes a type of cable and a form of connector that is mainly used in recording and playback devices in professional broadcasting. HD-SDI is an extension of this standard. It enables a data transmission rate that allows digital image recording and playback in high-definition quality. Coaxial cables or optical fibres are used as SDI and HD-SDI cables. The primary task of the HD-SDI slip rings is therefore to ensure interference-free signal transmission at all times.

QQ图片20230322163852

Our advantage:

  • Company advantage: We offer standardized modularized design and fully customizable products, according to customers’ special requirements and various applications. If you have special customized requirements, please feel free to contact us so that we can make the best recommendation for your specification.
  • Product advantage: High rotating accuracy, more stable performance and longer service life. The lifting material is precious metal + superhard gold plating, with small torque, stable operation and excellent transmission performance. 10 million revolutions of quality assurance.
  • Excellent after-sales and technical support service, by providing high-quality products and technical services, Ingiant has become the long-term designated qualified supplier for numerous military units &research institutes, domestic and foreign companies.

QQ截图20230322163935
