Ingiant inner diameter 70mm through hole slip ring 20 channels 1A
|
DHK070-20-1A |
|||
|
Main Parameters |
|||
|
Number of circuits |
20 |
Working temperature |
“-40℃~+65℃” |
|
Rated current |
2A.5A.10A.15A.20A |
Working humidity |
＜70% |
|
Rated voltage |
0~240 VAC/VDC |
Protection level |
IP54 |
|
Insulation resistance |
≥1000MΩ @500VDC |
Housing material |
Aluminum Alloy |
|
Insulation strength |
1500 VAC@50Hz,60s,2mA |
Electrical contact material |
Precious metal |
|
Dynamic resistance variation |
＜10MΩ |
Lead wire specification |
Colored Teflon insulated & tinned stranded flexible wire |
|
Rotating speed |
0~600rpm |
Lead wire length |
500mm + 20mm |
Standard product outline drawing:
DHK070-20-1A Series Through Hole Slip Ring
DHK070-20-1A Series standard through hole slip ring with outer diameter of 145mm and through-hole diameter of 70mm (applicable to <=70mm), 20-channel power, 1A per channel. Supports mixed transmission of signals and power, and can customize the number of circuits and current and voltage based on standard models.
Features
- Multi-point brush contact material ensures long life
- Integrated structure design, easy installation
- 20 channels 1A each
- IP 54 (customizable IP65-IP68)
- Compatible with two data bus protocols
- Maintenance-free
Typical applications:
Radar, security equipment, entertainment equipment, various robots, manipulators, various airships, various wind power equipment, bottle blowing machines, light inspection machines, various turntables, amusement equipment, vehicle-mounted satellite antennas, ship-mounted satellite wires, cable reels, window cleaning equipment, revolving tables, revolving stages, revolving screens, revolving restaurants, electric engineering machinery, etc.
