Ingiant Military aviation plug optoelectronic slip ring OD 90mm Single channel optoelectronic slip ring
|
DHS090-50-1F |
|||
|
The main parameters |
|||
|
Number of circuits |
50 |
Working temperature |
“-40℃~+65℃” |
|
Rated current |
can be customized |
Working humidity |
＜70% |
|
Rated voltage |
0~240 VAC/VDC |
Protection level |
IP54 |
|
Insulation resistance |
≥1000MΩ @500VDC |
Housing material |
Aluminum Alloy |
|
Insulation strength |
1500 VAC@50Hz,60s,2mA |
Electrical contact material |
Precious metal |
|
Dynamic resistance variation |
＜10MΩ |
Lead wire specification |
Colored Teflon insulated & tinned stranded flexible wire |
|
Rotating speed |
0~600rpm |
Lead wire length |
500mm + 20mm |
Standard product outline drawing:
Military aviation plug optoelectronic slip ring
DHS090-60-1F is a optoelectronic slip ring with aviation plugs on both the rotor and stator, outer diameter 90mm, supports single mode and multi-mode.which is convenient for loading, unloading, replacement and installation, eliminating the trouble of welding wires and improving stability and reliability. It uses optical fiber as a data transmission carrier, which is suitable for harsh environments and solves the rotation transmission problem for optical series and optoelectronic systems.
Features:
- Both the rotor and stator are equipped with aviation plugs.
- Single channel optoelectronic slip ring
- Easy to maintain and replace.
- IP51-IP68 optional.
- Adopting advanced precious metal cluster brush multi-point contact, reliable contact is ensured under extremely low friction.
Typical applications:
Military armored vehicle turntables, military robots, shipborne radar turntables, ship electric thrusters, missile launches, airborne radar turntables, radar guidance, airborne early warning systems, defense systems, etc.
Our advantage:
- Product advantage: Cost effective,High quality,IP protection rated,Suitable for extreme environments, Explosion proof units, High reliability low maintenance, Integration of high frequency channels , Standard units and custom design, Transmission of high definition video with high frame rate, 360 degree continuous panning, Integration of rotary joints and Ethernet, Fully gimbaled systems, Twist capsule integration ,Long life.
- Company advantage: We have more than 50 national patents, and a experienced R&D team with more than 10 years experienced senior engineers in the industry, more than 100 workers with several years experience in workshop production, skilled in operation and production, can better guarantee product quality.
- Excellent after-sales and technical support service:Customized, accurate and timely service for customers in terms of pre-sales, production, after-sales and product warrenty, our goods are guaranteed for 12 months from date of sale,under guaranteed time non human damage, free maintenance or replacement for quality problems arising from the products.
