Ingiant Military quality 4-channel 100M Ethernet slip ring 60mm hollow shaft structure
|
DHK060-75 |
|||
|
The main parameters |
|||
| Number of circuits | 75 | Working temperature | “-40℃~+65℃” |
| Rated current | 2A.5A.10A.15A.20A | Working humidity | ＜70% |
| Rated voltage | 0~240 VAC/VDC | Protection level | IP54 |
| Insulation resistance | ≥1000MΩ @500VDC | Housing material | Aluminum Alloy |
| Insulation strength | 1500 VAC@50Hz,60s,2mA | Electrical contact material | Precious metal |
| Dynamic resistance variation | ＜10MΩ | Lead wire specification | Colored Teflon insulated & tinned stranded flexible wire |
| Rotating speed | 0~600rpm | Lead wire length | 500mm + 20mm |
Standard product outline drawing:
DHK060-75 series 4-channel 100M Ethernet slip ring
4 sets of 100M network cables + 55 channels of power current/signal
DHK060-75 series of 100M Ethernet slip rings are integral precision conductive slip rings that can be rotated 360 degrees to transmit 4 channels of 100M Ethernet signals. The slip ring aperture is 60mm and can mix and transmit 55 channels of current/signal. It can mix USB, HDMI, etc. other signals. It has the advantages of stable transmission, no packet loss, no aliasing, small return loss, and small insertion loss.
Features
- Standard RJ45 connector, optional RJ45 female connector;
- Stable transmission of 4 channels of 100M Ethernet signals;
- Mainly able to transmit Ethernet (10M / 100M / 1000M BaseT);
- It can also work with current channels or gas-liquid rotary joints;
- Mixed transmission of 55 channels of power/current/signal;
- It has the advantages of stable transmission, no packet loss, no aliasing, small return loss, and small insertion loss;
Our Advantage
1） Product advantage: Specification can be customized, like inner diameter, rotating speed, housing material and color, protection level. Light in weight and compact in size, easy to install. Unique integrated high frequency rotary joints that demonstrate great stability when transmitting signals. Product with small torque, stable operation and excellent transmission performance, more than 10 million revolutions of quality assurance, longer using life. Built-in connectors facilitate installation, reliable signals transmission, no interference and no package loss.
2） Company advantage: After years of experience accumulation, Ingiant has a database of more than 10,000 slip ring scheme drawings, 27 kinds of technical patents of slip rings and rotary joints(include 26 untility model patents, 1 invention patent), and has a very experienced technical team who use their technology and knowledge to provide global customers with perfect solutions.
3） Customized service, accurate response and technical support for customers, 12 months of the products warranty, no worry for after sales problems. With reliable products, strict qualitycontrol system, perfect pre-sale and after-sales service, Ingiant obtain strusts from more and more customers all over the world.
