Ingiant OD 45mm rotor flange slip ring transmits 81 channels signals (3A) and 14channels power (10A/25A)

Standard product outline drawing:

Rotor flange slip ring: OD 45mm solid shaft slip ring

DHS045-95 series rotor flange slip ring ,solid slip ring,outer diamete 45mm, and the rotor part is connected to the flange , no through hole in the center, suitable for flange end face installation. It transmits 81 channels signals (3A) and combines with 5 channels power rings (10A) , 9 channels power rings (25A) . Customized design according to actual needs.

Features:

• Transmit analog and data signals
• Compatible with data bus protocol
• Long life, maintenance-free
• Easy to install
• The brush contact part is plated with rare precious metals, which has a long service life
• 360°continuous rotation to transmit power and data’signals

Typical applications:

Various cable reels, filling machines, molding machines, human health detection equipment, robotic arms, surgical lights, shadowless lamps, heaters, LED advertising lights, cable reels, grinding and polishing machines, spraying equipment, storage and logistics vehicles, cranes, single crystal furnaces, sweeping robots with cameras, roasting machines, etc.

Our advantage:

• 1）Product advantage: Transmit analog and digital signal；Adopts gold-to-gold contact to transmit signal；Able to integrate up to 135 channels；Module design, guarantees consistency of the products；Compact structure, small size；Adopt special soft wire ；Long life, maintenance-free, easy to install, more stable performance and 360°continuous rotation to transmit power and data siganls.
• 2）INGIANT adheres to the business philosophy of “customer-centered, quality-based, innovation-driven”, seeks to win the market with high-quality products and considerate services, in terms of pre-sales, production, after-sales and product warrenty, we provide customized service to meet various demands of clients so Ingiant obtained a excellent reputation from the industry.
• 3）Excellent after-sales and technical support service, by providing high-quality products and technical services, Ingiant has become the long-term designated qualified supplier for numerous military units &research institutes, domestic and foreign companies.
