Ingiant seperate slip rings with through hole 60mm and 10 channels power without housing

Standard product outline drawing:

Separate slip rings & brushes without housing

Slip rings without housing for complete integration into customer systems, individual composition possible

DHK060-10-002 Seperate slip rings are available in 10 channels. Each channel can pass a rated current of 2-10 amps. The maximum working voltage is 240 volts for alternating current and 440 volts for direct current. Rotor and brush holder are supplied separately for flexible integration into installations. Rotor unit also available as hollow shaft version with different inner diameters. Screw or adhesive mounting. Customised and combined power and signal versions possible.

Seperate slip rings have the following advantages:

• Extremely space-saving
• Extremely low weight
• Easily integrated into existing, open systems
• Made to standard dimensions
• Easy to replace
• Repairable within narrow limits
• Corrosion-resistant contacts
• Minimal wear

Typical applications:

• Actuator motors in hydraulic or pneumatic control systems
• Three-phase motors with internal speed monitoring
• Rotary switches on control cabinets
• Extremely space-saving drive and control combinations for drones and models

Our Advantage

• 1） Product advantage: Specification can be customized, like inner diameter, rotating speed, housing material and color, protection level. Light in weight and compact in size, easy to install. Unique integrated high frequency rotary joints that demonstrate great stability when transmitting signals. Product with small torque, stable operation and excellent transmission performance, more than 10 million revolutions of quality assurance, longer using life. Built-in connectors facilitate installation, reliable signals transmission, no interference and no package loss.
• 2） Company advantage: After years of experience accumulation, Ingiant has a database of more than 10,000 slip ring scheme drawings, 27 kinds of technical patents of slip rings and rotary joints(include 26 untility model patents, 1 invention patent),  and has a very experienced technical team who use their technology and knowledge to provide global customers with perfect solutions.
• 3） Customized service, accurate response and technical support for customers, 12 months of the products warranty, no worry for after sales problems. With reliable products, strict qualitycontrol system, perfect pre-sale and after-sales service, Ingiant obtain strusts from more and more customers all over the world.
