Ingiant standard DHK012 series micro-aperture through-hole conductive slip ring 48 channels 5A

Short Description:



Features

Supports each channel signal (5A), current (5A, optional multiplier *5A, such as 10A/each channel); maximum speed: general grade 250RPM, industrial grade 600RPM, high-end grade 1000RPM; standard model supports 2~12 channels (each 5A) current; the contact material is made of precious metal + super-hard gold plating; the resistance fluctuation is small and the contact resistance is small, ensuring excellent transmission performance.


Product Detail

Product Tags

DHK012-48-5A

The main parameters

Number of circuits

48

Working temperature

“-40℃~+65℃”

Rated current

2A.5A.10A.15A.20A

Working humidity

<70%

Rated voltage

0~240 VAC/VDC

Protection level

IP54

Insulation resistance

≥1000MΩ @500VDC

Housing material

Aluminum Alloy

Insulation strength

1500 VAC@50Hz,60s,2mA

Electrical contact material

Precious metal

Dynamic resistance variation

<10MΩ

Lead wire specification

Colored Teflon insulated & tinned stranded flexible wire

Rotating speed

0~600rpm

Lead wire length

500mm + 20mm

Standard product outline drawing:

DHK012-II



The DHK012 series is a micro-aperture through-hole conductive slip ring with a via hole diameter of 12mm (applicable to any rotating device with an aperture ≤12mm). The DHK012 series is a small-aperture, low-current, micro-integrated structure precision conductive slip ring that can stably transmit 5A Current (magnification * 5A) or signal, can be used for pipeline cameras (pipeline camera robots), underwater surveillance cameras, pipeline detectors, industrial endoscopes, CCD visual inspection equipment, intelligent equipment machine vision systems, intelligent equipment machine vision systems, Labeling machine, intelligent dispensing machine, mobile phone laminating machine, automatic assembly machine, automatic packaging machine, rotating LED light, disassembly machine, automatic pin insertion machine, automatic toothpick packaging machine, fully automatic folder gluing machine, experimental equipment, biology Detector

Features

Supports each channel signal (5A), current (5A, optional multiplier *5A, such as 10A/each channel); maximum speed: general grade 250RPM, industrial grade 600RPM, high-end grade 1000RPM; standard model supports 2~12 channels (each 5A) current; the contact material is made of precious metal + super-hard gold plating; the resistance fluctuation is small and the contact resistance is small, ensuring excellent transmission performance.

slip ring application 3

Our Advantage

  1.  Product advantage: continuous transmission of power, signals, weak current, high current, high voltage under 360 degree unrestrained rotations. Low torque, low electrical noise, low loss and easy maintenance as the main features.
  2.  Company advantage:  As manufacturer of various slip ring bodies,Ingiant elies on a combination of targeted design processes, a selection of the best raw materials, professional production conditions, 100% quality control and professional assembly at the customer’s site.
  3. Customised advantage: we offer modular slip ring systems that can be completely individually adapted to your needs. our slip ring bodies are convincing even under rough environmental conditions and temperatures.
