Ingiant standard series through hole slip ring hole diameter 150mm 7 channels power

Short Description:

Product Detail

Product Tags

DHK150-7
The main parameters
Number of circuits	7	Working temperature	“-40℃~+65℃”
Rated current	2A.5A.10A.15A.20A	Working humidity	＜70%
Rated voltage	0~240 VAC/VDC	Protection level	IP54
Insulation resistance	≥1000MΩ @500VDC	Housing material	Aluminum Alloy
Insulation strength	1500 VAC@50Hz,60s,2mA	Electrical contact material	Precious metal
Dynamic resistance variation	＜10MΩ	Lead wire specification	Colored Teflon insulated & tinned stranded flexible wire
Rotating speed	0~600rpm	Lead wire length	500mm + 20mm

Standard product outline drawing:

DHK150-7 series through hole slip ring, through hole diameter 150mm

DHK150-7 is a standard series through hole slip ring, through hole diameter 150mm (applicable to any <=150mm), 7-channel power precision conductive slip ring. Support power 10A, magnification *10A, voltage 440VAC/VDC. High rotation accuracy, more stable performance, longer life. The contact material is made of precious metal + super-hard gold plating, with small torque, stable operation, long life, small resistance fluctuation, small contact resistance, and excellent transmission performance.

Typical applications include automation equipment, work turntables, camera pans, robots, etc.

Product features

Integrate power, signal and data in a rotating transmission system without interference
Transmit temperature control signal and thermocouple signal at the same time
Brush bundle process ensures reliable contact and low friction coefficient
Multi-contact brush contact design, long service life
Integrated structure design, easy installation
IP 54 protection level, customizable IP68
Can integrate multiple signals, compatible with multiple data protocols
Maintenance-free use

Our Advantage

1）Product advantage: DHK series perforated conductive slip ring is currently the most cost-effective industrial slip ring inside a best-selling series of products, in many cases also known as hollow shaft conductive slip ring, through the hole, through the hole conductive slip ring, hollow shaft slip ring. Mainly used in 360 degrees continuous rotation and need to ensure that the power supply, signal can not be interrupted:

2）Company advantage: The R&D team of Ingiant has strong research and development strength, rich experience, unique design concept, advanced testing technology, as well as years of technical accumulation and cooperation and absorption of foreign advanced technology, making our technology always maintain the international leading level and lead the industry.

3）Excellent after-sales and technical support service:Customized, accurate and timely service for customers in terms of pre-sales, production, after-sales and product warrenty, our goods are guaranteed for 12 months from date of sale,under guaranteed time non human damage, free maintenance or replacement for quality problems arising from the products.
