Ingiant Standard through hole 60mm 100M Ethernet slip ring with 2 channels 2A power and 3 channels 2A signal

Standard product outline drawing:

DHK060-10 series Ethernet slip ring, 1 channel 100M Ethernet （4channels 2A）precision conductive slip ring with inner hole 60mm and outer diameter of standard 130mm hollow shaft structure, mixed transmission 2 channels of power 2A current, 3 channels of 2A signal. It has the advantages of stable transmission, no packet loss, no string code, small return loss, small insertion loss, etc. American military coating technology, precious metal + super hard gold plating treatment, ultra-low BER bit error rate and ultra-high signal-to-noise ratio.

Features

• Multi-point brush contact material ensures long life
• Stable transmission of 100M Ethernet signal
• Integrated structure design, easy to install
• Standard models and customized models available
• IP51 (customizable IP54-IP68)
• Equipped with RJ45 male interface, RJ45 female optional
• Ethernet cable connection
• It has the advantages of reliable transmission, no packet loss, no string code, low return loss, low insertion loss, etc.
• Free maintenance

Typical applications: Automatic machines, cable reels, robots, rotary sensors, emergency lighting equipment, exhibition/display equipment, packaging machinery, rotary tables, medical, pharmaceutical equipment, processing machinery, capping machines, labeling machines, filling machines, machine tools.

Our Advantage

1.   Product advantage: Specification can be customized, like inner diameter, rotating speed, housing material and color, protection level. Light in weight and compact in size, easy to install. Unique integrated high frequency rotary joints that demonstrate great stability when transmitting signals. Product with small torque, stable operation and excellent transmission performance, more than 10 million revolutions of quality assurance, longer using life. Built-in connectors facilitate installation, reliable signals transmission, no interference and no package loss.
2. Company advantage: After years of experience accumulation, Ingiant has a database of more than 10,000 slip ring scheme drawings, 27 kinds of technical patents of slip rings and rotary joints(include 26 untility model patents, 1 invention patent),  and has a very experienced technical team who use their technology and knowledge to provide global customers with perfect solutions.
3.  Customized service, accurate response and technical support for customers, 12 months of the products warranty, no worry for after sales problems. With reliable products, strict qualitycontrol system, perfect pre-sale and after-sales service, Ingiant obtain strusts from more and more customers all over the world.
