Application and characteristics of medium frequency conductive slip ring

The medium frequency conductive slip ring is a mechanical transmission device that realizes electrical connection between the conductive ring in the rotating bearing body and the brush in the stationary bearing body, transmits electrical energy from the fixed part to the rotating part, and realizes electrical grounding on the rotating part. The frequency of the transmitted current is usually between 1 kHz and 1 MHz, so it is called a medium frequency conductive slip ring. It is a mechanical device that transmits high-frequency electrical energy from the fixed part to the rotating part. It is usually used in high-frequency induction heating equipment. Its main function is to transfer high-frequency current from the power supply to the induction coil on the rotating part to generate a magnetic field and heat the workpiece. This article will introduce the medium frequency conductive slip ring from three aspects: definition, application field and characteristics.

smart

What are the characteristics of medium frequency conductive slip ring?

  • High efficiency: The medium frequency conductive slip ring is made of conductive material, which can effectively transmit power signals and realize grounding on the rotating part to avoid the loss of electric energy.
  • Good stability: The medium frequency conductive slip ring has good stability and durability, and can withstand harsh conditions such as high-speed rotation, complex working environment, high temperature and high pressure.
  • Simple maintenance: The maintenance of medium frequency conductive slip rings is relatively simple, and only requires timely cleaning and replacement of brushes.
  • Safe and reliable: The medium frequency conductive slip ring can establish an electrical connection between the rotating part and the fixed part, reduce the use of power cords, and avoid safety accidents caused by cable twisting or breakage.
  • Easy installation: The installation of medium frequency conductive slip rings is relatively simple, and only requires the bearing body and the rotating part to be fixed by bolts.

Medium frequency conductive slip rings are an important mechanical equipment, which are widely used in aluminum electrolytic cells, frequency converters, induction heating equipment and rotating machinery. Its high efficiency, good stability, simple maintenance and safety and reliability make it an indispensable part of modern mechanical transmission systems.



Application of medium frequency conductive slip rings

  1. Aluminum electrolytic cell: The medium frequency conductive slip ring of the aluminum electrolytic cell can transmit the power supply from the fixed part to the rotating anode, and generate a magnetic field on the anode, so that the aluminum ions in the electrolyte solution are reduced to aluminum metal.
  2. Inverter: The medium frequency conductive slip ring of the inverter can transmit the power signal from the fixed part to the rotating part to ensure the stable operation of the inverter.
  3. Induction heating equipment: Medium frequency conductive slip rings are usually used in high frequency induction heating equipment, which can transfer high frequency current from the power supply to the rotating induction coil to generate a magnetic field and heat the workpiece.
  4. Rotating machinery: Medium frequency conductive slip rings can be used in the field of rotating machinery, such as rotary grinders, rotary pipe bender and other equipment to achieve electrical connection and energy transmission.
