Standard hole diameter 90mm series Gigabit Ethernet Slip Ring transmission 3channels Gigabit Ethernet signals

Short Description:

Gigabit Ethernet Slip Ring DHK090-47 Series

DHK090-47 is a through-hole Ethernet slip ring with an inner diameter of 90mm and an outer diameter of 165mm. It can be used to install rotating systems with shaft diameters less than or equal to 90mm, and supports a maximum of 18 channels of power, 72 channels of signals, and 3 channels of Gigabit Ethernet. Gigabit Ethernet slip rings have high-speed transmission characteristics, provide communication bandwidth up to 1Gbps, are compatible with traditional Ethernet technical specifications, are cost-effective, easy to unified management, and convenient for iterative upgrades.

Send email to us

Product Detail

Product Tags

DHK090-47
The main parameters
Number of circuits	47	Working temperature	“-40℃~+65℃”
Rated current	2A.5A.10A.15A.20A	Working humidity	＜70%
Rated voltage	0~240 VAC/VDC	Protection level	IP54
Insulation resistance	≥1000MΩ @500VDC	Housing material	Aluminum Alloy
Insulation strength	1500 VAC@50Hz,60s,2mA	Electrical contact material	Precious metal
Dynamic resistance variation	＜10MΩ	Lead wire specification	Colored Teflon insulated & tinned stranded flexible wire
Rotating speed	0~600rpm	Lead wire length	500mm + 20mm

Standard product outline drawing:

Gigabit Ethernet Slip Ring DHK090-47 Series

Features

Stable transmission of 3-channel Gigabit Ethernet signals
The contact part of the brush is plated with rare precious metals and has a long service life.
Plug and play RJ45 interface
Dedicated Ethernet cable
Easy installation and maintenance-free use
Stable transmission, no packet loss, no cross-coding, large return loss, low insertion loss

Ethernet slip rings are mostly used in high-definition video surveillance systems, transmitting high-definition video signals for dome cameras and PTZ pan-tilt cameras, and providing effective solutions for 360-degree rotating security monitoring.

Our advantage:

1：Product advantage: Ingiant Ethernet slip rings are made of reliable precious metal materials and aluminum housings. Mature and stable technology enables the production of slip rings with remarkable features such as stable transmission, no packet loss, anti-crosstalk, large return loss and low insertion loss.

2：Customized service, accurate response and technical support for customers, 12 months of the products warranty, no worry for after sales problems. With reliable products, strict qualitycontrol system, perfect pre-sale and after-sales service, Ingiant obtain strusts from more and more customers all over the world.

3：INGIANT adheres to the business philosophy of “customer-centered, quality-based, innovation-driven”, seeks to win the market with high-quality products and considerate services, in terms of pre-sales, production, after-sales and product warranty, we provide customized service to meet various demands of clients so Ingiant obtained a excellent reputation from the industry.
